Overview

Faraday® Thermal Protection Systems were initially designed to protect boost vehicles from both extreme temperatures and lightning threats.  Over the years, this system has become a bespoke shielding solution for a variety of applications.  Faraday’s unique design allows it to be custom-tailored to fit your specific needs.  Its all-carbon design provides exceptional thermal and environmental stability, while also protecting your vehicle from a diverse range of threats, including:

  • Extreme Temperatures
  • Lightning Strikes
  • EMI/EMP
  • Lasers
  • Radiation

Design

Faraday TPS introduces an innovative layered approach to the industry that allows for complete customization to meet customer needs.  Individual layers can be added, removed, or altered independently from each other to meet each application’s specific threat profile for a truly SWAP-C optimized system.

The Faraday system can be fit to a variety of complex geometries across a range of sizes from small, tactical applications to large boost vehicles.

The article pictured here has an inner diameter just over 54 inches (1.37 meters) and is 5 feet (1.52 meters) tall:

Testing

Faraday systems have survived a grueling testing regime involving lighting strikes up to 200kA, aerothermal testing up to 1093°C (2000°F) at Mach 4, and extensive environmental stability tests per MIL-STD-810H.

To simulate a representative mission profile, Touchstone exposed panels to a simulated launch environment.  Then, those same panels were sent for lightning strike testing.  And finally, they were tested in a hot gas flow chamber to simulate various aero loads.  These panels performed their duty despite this abuse.

The below video shows a standards TPS panel going through aero testing:

History

Since the 1990’s when Touchstone assisted NASA’s Marshall Space Flight Center in the development of the MCC-1 TPS for the Space Shuttle’s Solid Rocket Booster, Touchstone has been researching and developing novel concepts for next-generation thermal protection systems for rockets.
Touchstone has developed both ablative and non-ablative TPS systems.  Amongst the materials used in the designs are CFOAM carbon foam, carbon aerogels, Silicon Carbide, carbon-carbon, cork, glass beads, and more.
Touchstone has also provided an array of thermomechanical testing for both metallic and non-metallic thermal protection systems.

Contact

For more information, email faradaytps@trl.com
